The SMART Fabrication Factory is a prototyping facility whose mission focuses on developing collaborative research with industry.

About the Fabrication Factory

In response to SMART’s grand challenge to develop advanced materials, technologies and processes that enable the sustainable, data-driven, cost effective production of high quality, customizable products, the factory provides space and instrumentation to build full scale, testable prototypes. The factory contains a 3axis OMAX Maxiem 1530 waterjet cutter, a Universal Laser Systems laser cutter and an L&L frontloading kiln. In addition it has room to house architectural scaled projects.

Who is this facility open to?

Faculty • Staff • Students • Researchers at other academic institutions • Government and industry

FACILITY INFORMATION

Location:
56 Parker Hall, South Campus

Daniel Vrana
Email: danielvr@buffalo.edu
Phone: (716) 829-3510

Schedule a tour anytime! Email or call Daniel Vrana to set up your tour.

Equipment

OMAX Maxiem 1530 JetMachining Center with A-Jet Multi-Axis Cutting Head

The OMAX Maxiem 1530 waterjet cutter is a large format machine capable of cutting virtually any material (metal, stone, glass, plastic, composites) up to 10’0” x 5’2” and up to 6” thick using a high pressure stream of water mixed with abrasive.

Read More

With the addition of the OMAX A-Jet multi-axis cutting head, the machine is able to cut three-dimensional angles ranging from 0 degrees to 60 degrees, proving useful in practical applications such as beveling parts prior to welding or aesthetic applications for complex three-dimensional parts.  While traditional three-axis waterjet cutting heads subject parts to edge taper due to the spreading of the water stream during cutting, the A-Jet cutting head compensates for this taper through subtle tilting, yielding parts with vertical edges and redistributing stream taper into the scrap portions of the material.  The Intelli-MAX Software suite of software completes the package and includes capability to import two-dimensional CAD drawings, import three-dimensional CAD parts, draw parts from scratch, visualize parts, and output parts for cutting.

Optional accessories included with this machine: scissor-style hard plumbing, Bulk Abrasive Delivery System (capable of holding 600 pounds of abrasive for distribution to the machine’s abrasive hopper), and the Variable Speeds Solids Removal System (removing abrasive from the tank and filtering water for more cut time without emptying the tank).

Universal Laser Systems ILS12.150D Platform

The ULS ILS12.150D laser cutting system contains dual 60W lasers and can process an area of 24” x 48” up to 12” tall (the machine is NOT capable of cutting through the full height but can be used for engraving up to 12”).

Learn More

The machine contains a versatile 2.0” lens, providing a balance between spot size, depth of focus, and focal length.  While the 2.0” lens does not allow for much deviation in material thickness / flatness, it provides accuracy in cutting and engraving.

The optional Flow-Through Cutting Table is included which allows for reduced marking on the underside of materials being cut through.

L&L Kilns Easy-Load Front-Loading Kiln EL3048

The Easy-Load Kiln has an internal size of 31” x 31” x 48” tall and is capable of heating up to 2350 degrees Fahrenheit (Cone 10).

See More

There are three separate zones which are controlled by the Dyna-Trol Program Control (allowing users access to 4 Easy-Fire programs, 6 Vary-Fire programs, Pre-Heat, Delay, Program and Segment Review, and Diagnostics).  The kiln insulation system includes a 4.5” thick brick arch, 3” of firebrick with 2” of mineral wool back-up, and a plug door.

The optional shelf kit is included which contains 14” x 28” shelves, heat resistant gloves, Cone 10 kiln wash, and square posts at .5”, 1”, 2”, 4”, 6”, and 8” heights.
